| Thermal |
| Detector Type |
Vanadium Oxide Uncooled FPA |
| Max. Resolution |
256 × 192 |
| Pixel Pitch |
12 μm |
| Spectral Range |
8 μm–14 μm |
| Thermal Sensitivity (NETD) |
< 50 mK (@f/1.0,25 Hz,300K) |
| Focal Length |
2 mm |
3.5 mm |
7 mm |
| Field of View |
H:87.8°, V: 63.8° |
H: 50.6°, V: 37.8° |
H: 24°, V: 18° |
| Close Focus Distance |
0.3 m (0.98 ft) |
0.5 m (1.64 ft) |
1.0 m (3.28 ft) |
Effective Distance
Human (1.8 m × 0.5 m) |
D: 83 m (272 ft)
R: 21 m (69 ft)
I: 11 m (36 ft) |
D: 146 m (479 ft)
R: 38 m (125 ft)
I: 19 m (622 ft) |
D: 292 m (958 ft)
R: 75 m (246 ft)
I: 38 m (125 ft) |
Effective Distance
Vehicle (4.0 m × 1.4 m) |
D: 222 m (728 ft)
R: 55 m (80 ft)
I: 27 m (89 ft) |
D: 389 m (1276 ft)
R: 97 m (318 ft)
I: 49 m (161 ft) |
D: 778 m (2552 ft)
R: 194 m (636 ft)
I: 97 m (318 ft) |
| Aperture |
F1.0 |
Digital Detail
Enhancement (DDE) |
Yes |
| Digital Zoom |
16 x |
| AGC |
Auto; Manual |
| Noise Reduction |
2D NR; 3D NR |
| Image Flip |
90°; 180°; 270° |
| Color Palettes |
18 (Whitehot/Blackhot/Ironrow/Icefire/Fusion/Rainbow/Globow/Iconbow1/Iconbow2 .etc) |
| Fusion Mode |
3 (Warm color; cool color; Ironred) |
| Visible |
| Image Sensor |
1/2.7” CMOS |
| Max. Resolution |
2336 × 1752 |
| Pixel |
4MP |
| Electronic Shutter Speed |
1/30000s–1s |
| Min. Illumination |
Color: 0.05 Lux
Black & white: 0.005 Lux
0 Lux (IR on) |
| IR Illumination Distance |
≥ 30 m (98.43 ft) |
| IR Illuminator On/Off Control |
Auto; Manual |
| Focal Length |
2 mm |
4 mm |
8 mm |
| Aperture |
F2.2 |
F1.6 |
F2.0 |
| Field of View |
H: 94°
V: 72°
D: 116° |
H: 71.2°
V: 52°
D: 92.6° |
H: 33.4°
V: 25°
D: 41.9° |
| Focus Control |
Fixed |
| Close Focus Distance |
0.3 m (0.98 ft) |
1.0 m (3.28 ft) |
2.5 m (8.2 ft) |
| Day/Night |
Auto (ICR); Color and B/W |
| BLC |
Yes |
| WDR |
DWDR |
| HLC |
Yes |
| White Balance |
Auto/Manual/Indoor/Outdoor/Tracking/Street lamp/Natural |
| AGC |
Auto; Manual |
| Noise Reduction |
2D NR; 3D NR |
| S/N Ratio |
≥ 55 dB |
| Region of Interest (RoI) |
Yes |
| Image Flip |
90°; 180°; 270° |
| Exposure Compensation |
Yes |
| Intelligence |
| General Intelligence |
Tripwire, Intrusion |
| Advanced Intelligence |
Fire Detection & Alarm
Cold & Hot Spot Trace
Human & Vehicle Classification
Smoking Detection
Call Detection |
| Temperature Measurement |
| Temperature Range |
Low Temperature Mode: -20°C to +150°C (-4°F to +302°F) High Temperature Mode: 0°C to +400°C (+32°F to +752°F) |
| Temperature Accuracy |
Max (±5°C, ±5%) Operating Temperature: -30°C to +60°C (-22°F to +140°F) |
| Temperature Mode |
Spot: 12
Line: 12
Area: 12
Support 12 rules simultaneously |
| Video and Audio |
| Video Compression |
H.265/H.264M/H.264H/H.264B/MJEPG |
| Resolution |
Thermal:
Main Stream: 1280 × 960 (1.3M) /XVGA (1024 × 768) /VGA (640 × 480) /256 × 192, 1280 × 960 by default
Sub Stream: VGA (640 × 480) /256 × 192, 256 × 192 by default
Visual:
Main Stream: 2336 × 1752/1080p (1920 × 1080) /720p (1280 × 720) /D1 (704 × 576), 2336 × 1752 by default
Sub Stream: 720p (1280 × 720)/D1 (704 × 576) /CIF (352 × 288), 352 × 288 by default |
| Frame Rate |
Thermal
50 Hz: (main stream) 1 fps–25 fps adjustable, 25 fps by default; (sub stream) 1 fps–25 fps adjustable, 15 fps by default
60 Hz: (main stream) 1 fps–30 fps adjustable, 30 fps by default; (sub stream) 1 fps–30 fps adjustable, 15 fps by default
Visual
50 Hz: (main stream) 1 fps–25 fps adjustable, 25 fps by default; (sub stream) 1 fps–25 fps adjustable, 15 fps by default
60 Hz: (main stream) 1 fps–30 fps adjustable, 30 fps by default; (sub stream) 1 fps–30 fps adjustable, 15 fps by default |
| Audio Compression |
G.711a; G.711mu; PCM |
| Network |
| Protocol |
HTTPS; HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP |
| Edge Storage |
Micro SD card (256 G) |
| Interoperability |
ONVIF; CGI |
| Browser |
IE: IE8 and the later, and explorer with IE core
Google: 42 and the earlier
Firefox: 42 and the earlier |
| User/Host |
10 |
| Security |
Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access |
| Certification |
| Certifications |
CE: EN55032:2015; EN61000-3-2:2014
FCC:CFR 47 FCC Part15 subpart B; ANSI C63.4-2014 |
| Port |
| Network |
1 10 M/100 M Ethernet port (RJ-45) |
| Audio Input |
1 |
| Audio Output |
1 |
| Alarm Input |
1 |
| Alarm Output |
1 |
| RS-485 |
1 pair |
| Power |
| Power Supply |
12 V±20% DC/PoE |
| Power Consumption |
Basic: < 6.5 W (LED off)
Max: < 13 W (LED on,heater on) |
| Environment |
| Operating Temperature |
–30 °C to +60 °C (–22 °F to ﹢140 °F) |
| Storage Temperature |
–30 °C to +70 °C (–22 °F to ﹢158 °F) |
| Operating Humidity |
≤ 95% |
| Protection |
IP67, anti-surge 6KV, anti-elctrostatic 6KV (touched by objects), anti-elctrostatic 8KV (air) |
| Structure |
| Product Dimensions |
122 mm × 122 mm × 112 mm (4.8″ × 4.8″ × 4.41″) |
| Packaging Dimensions |
155 mm × 155 mm × 135 mm (6.10″ × 6.10″ × 5.31″) |
| Net Weight |
≤ 0.85 kg (1.87 lb) |
| Gross Weight |
≤ 1 Kg (2.20 lb) |
